Xeon Scalable - What you need to know

New platform, New Branding... We're here to help you make sense of it all.

By
July 11, 2017 at 12:30 PM
Intel Xeon Scalable Family

The wait is over and we can now release official information about Intel's biggest data center launch in a decade - Purley. Intel is doing things differently this time, bringing with this launch a completely new branding for Xeon. On this article we will cover these details, as well as show you the launch lineup that is available now.

What is Purley?

The Purley platform represents a unified stack of branding and technologies to the business, enterprise and data center markets.

At launch, Purley is comprised of the following:


Lewisburg Chipset: Purley features a new platform core-logic with Lewisburg. It features the new DMI3 chipset-bus, which translates to four lanes of PCI-Express 3.0 physically. On the networking front, Lewisburg offers support of up to four 10GbE interfaces.


Skylake Processor: Built on the 14nm process, Skylake CPUs launching with Purley will feature up to 28 physical cores, with HyperThreading enabling 56 logical CPUs, and for the first time,support for 6 channels of DDR4-2666. The TDP will range between 45W and 165W depending on processor SKU.


Workload Accelerators: With this release, certain applications can benefit greatly from accelerators built by Intel, both on the die and via software. Some of these accelerators are:

  • Intel® AVX-512 (2X FLOPs/core) for HPC, Analytics, Database and Security
  • Intel QuickAssist Technology: 2x faster crypto and compression
  • FPGA: 5X speedups on server, storage and network algorithms

New Fabric Technology: Purley replaces the InfiniBand technology with a newer, more advanced interconnect called Omni-Path. This technology allows for 100Gbps bandwidth with no loss of PCIe lanes.


E3-1200 v5 Performance

What's different from previous generations?

To put it simply, Purley has a ton of new capabilities and technologies:

E3-1200 v5 Performance

And here it is compared with the previous generation:

E3-1200 v5 Performance

Goodbye E5 and E7, Hello Scalable Processors

After almost a decade without any major branding changes, Intel is introducing a major branding refresh for the Xeon family. The new branding is now based on metals and their relative values: Bronze, Silver, Gold and Platinum.

E3-1200 v5 Performance New branding, as seen on Intel's official unveiling video.

Up to 28 cores / 56 threads in Skylake-SP

Intel Xeon Bronze: Aimed at entry level servers, delivering performance similar to that of the Xeon E5. Bronze chips generally will have less than 10 cores.

Intel Xeon Silver: According to Intel, Silver CPUs will offer "efficient performance at low power" and have 10-12 cores.

Intel Xeon Gold and Platinum: These processors will offer E7-like performance, as well as the most number of cores per CPU. Compared to the lower end offerings, Gold will offer better performance, more interconnect and accelerator engines, while Platinum will expand upon that, with more cores and specialized security features baked onto the die.

Skylake-SP SKUs

Last generations's Broadwell-EP was already a monster, offering up to 22 cores / 44 threads for some serious processing power. With the launch of Purley+Skylake, Intel has taken it to the next level, offering up to 28 cores / 56 threads per processor.

We have provided a list of SKUs for you below. We are currently working with Intel to make sure that this list is accurate, so this data should be considered preliminary, at least for now.

SKU Name Cores Base
Clock
TDP
Skylake-SP
8180 28 2.5GHz 205W
8176 28 2.1GHz 165W
8170 26 2.1GHz 165W
8168 24 2.7GHz 205W
8164 26 2.40GHz 120W
8160 24 2.60GHz 135W
6154 18 1.80GHz 55W
6152 22 1.70GHz 65W
6150 18 2.60GHz 85W
6148 20 3.50GHz 135W
6146 12 3.40GHz 135W
6142 12 3.20GHz 135W
6138 20 2.10GHz 120W
6140 18 2.10GHz 120W
6136 12 2.60GHz 145W
6144 8 2.30GHz 145W
6132 14 2.20GHz 135W
6130 16 2.20GHz 145W
6126 12 3.00GHz 160W
5120T 14 2.60GHz 135W
5118 12 1.80GHz 55W
5119T 14 1.70GHz 65W
6128 6 2.60GHz 85W
4116 12 3.50GHz 135W
5122 4 3.40GHz 135W
4114T 10 3.20GHz 135W
4114 10 2.10GHz 120W
4112 4 2.10GHz 120W
4108 8 2.60GHz 145W
3106 8 2.30GHz 145W
3104 6 2.20GHz 135W
Intel Xeon Inside

Skylake-SP

Skylake SP (Skylake Scalable Performance) is the code name for Intel's series of server multiprocessors based on the Skylake microarchitecture as part of the Purley platform serving as a successor to both Broadwell EX and Broadwell EP. These chips support up to 8-way multiprocessing, up to 28 cores, and incorporate a new AVX-512 x86 extension. Skylake SP-based chips are manufactured on an enhanced 14nm+ process and utilize the Lewisburg chipset. Skylake SP-based models are branded as the new processor families: Xeon Bronze, Xeon Silver, Xeon Gold, and Xeon Platinum.

Browse Compatible Servers

Codename Skylake-SP
Cycle Tock
Process Node 14nm
Platform Intel Purley
Socket LGA 3647
Released July 11, 2017
Predecessor Broadwell-EP
Broadwell-EX
This release combines single and multi-socket versions for the first time
Sucessor Not yet announced
Commonly used for
Software defined environments for data center, cloud and virtualization, Business Processing, R&D, Security,Cloud, Content creation and delivery
Core Count Up to 28
Scalability 2S/4S/8S+
TDP Up to 165W (Server)
Memory 6x DDR4 Channels
PCIe PCIe 3.0
40x PCIe 3.0 Lanes
Source: Thinkmate Internal Data and WikiChip


The SKU list is varied, With CPU cores ranging from 4 all the way up to the aforementioned 28. Clocks range from 1.7Ghz to 3.6Ghz. We're waiting for confirmation on L3 cache amounts from Intel, and we'll update once we receive them.

Comparing new branding vs old

Because Intel has completely overhauled the naming schemes, you may be wondering how you might be able to compare these new products vs. the old ones, which will not be retroactively renamed.

For this purpose, Intel has provided us a list of normalized performance numbers, which we are reproducing below. With this list, you should be able to have a better idea of performance relative to previously lanched products.

As you can see above, we have summarized the SKUs from the Xeon E5 v3 and v4 and aligned it with Xeon Scalable SKUs all the way up to Platinum 8180, sitting comfortably at the very top.

These results have been estimated based on internal analysis and are being provided for your convenience. Though it shouldn't be considered official, we think they can be helpful when upgrading and to help us get acclimated with the new branding. We are still going through the technical data provided to us by Intel, and we'll update this page if we feel there is something important to add.
